SINGLE GIRDER EOT CRANE.
A Single Girder EOT (Electric Overhead Travelling) Crane is a high-performance lifting system designed for safety, reliability, and smooth material handling.
It is ideal for light to medium-duty operations, offering maximum efficiency with minimum maintenance.
Energy Efficient Crane System
Single girder EOT cranes are designed with energy-efficient systems that help reduce power consumption and improve industrial productivity. These cranes provide smooth and reliable material handling performance with low operating costs, making them ideal for factories, warehouses, and heavy-duty industrial applications
KEY FEATURES
High-strength steel bridge girder designed for greater stability and long life.
✔ Smooth & Silent Operation
Equipped with premium-grade motors, gearboxes, and wire rope hoists.
✔ Low Headroom Design
Allows maximum lifting height even in compact industrial spaces.
✔ High Safety Standards
Emergency brake, overload protection, limit switches, and anti-collision sensors.
✔ Hassle-Free Maintenance
Modular components for quick servicing and part replacements.
✔ Energy Efficient
Low power consumption with maximum output.
Technical Specifications
| Parameter | Details |
|---|---|
| Specification | 1 Ton to 20 Ton |
| Span | Up to 30 meters |
| Lift Height | 6 meters (Standard Height) |
| Crane Class | Class II / III |
| Travel Speed | 10–20 m/min |
| Hoist Type | Electric Wire Rope Hoist |
| Control System | Pendant / Remote / VFD |
| Power Supply | 3 Phase AC |
Custom-Built Solutions
We provide tailor-made crane systems designed to match your industry needs, load requirements, and workspace layout.
Every crane is engineered for maximum performance, durability, and safety.
